 PIONEER MAGNETICS PRODUCT CATALOGUE Section 8

Click here for printable PDF document (section 8) - Click here for printable PDF document (entire catalogue)

  • LOW PROFILE POWER SUPPLIES
  • 1U POWER SUPPLIES
  • AC-DC POWER SUPPLIES
  • SINGLE OUTPUT POWER SUPPLIES

Pioneer’s introduces a 1U Low Profile High Efficiency PFC Series that provide full output power with 1φ AC Input. Designed to support both standalone and parallel configurations, these models are configured in standard Non-Plug and Hot Plug I/O interfaces. The Premium Quality front ends are rugged, reliable, designed for high performance and come in the low profile 1U x 5” package.With power density up to 25watts/in3, these units are featured with internal forced air-cooling and built-in protection from electrical over-loads.

A single module provides continuous full power over operating temperatures of 0°C to +50°C, from a Single AC Input line.
